List of Vessels Being Constructed for FSUE “Rosmorport”




Show allHide all
- operating as a lead ice breaker with high maneuvering and ice breaking capabilities (can move steadily in ice up to 2m thick);
- operating as an auxiliary ice breaker in convoys at the Northern Sea Route;
- self-maintained assistance to vessels in shallow arctic waters and in Siberia rivers estuaries;
- towage of vessels in ice and in ice-free water;
- providing assistance to vessels and conducting rescue operations in ice and in ice-free water;
- delivering necessary equipment and participating in oil leaks liquidation operations using onboard equipment;
- conducting underwater technical operations using onboard equipment and special systems at drilling and oil-extracting platforms, laying of underwater pipelines, exploration of sea bottom, conducting search and rescue operations;
- operating as a firefighting vessel during fire extinguishing at vessels, drilling and oil-extracting vessels;
- transporting scientific expeditions in the Arctic and Antarctic Regions (accommodation for 90 people, more than 300 sq. m of premises for scientific laboratories, also can take two heavy helicopters like MI-8 or KA-32 onboard);
- conducting other special works at sea.
Vessel rank: KM Icebreaker8 [2] AUT1-ICS OMBO DYNPOS-2 FF2WS EPP HELIDECK-H ANTI-ICE WINTERIZATION (-40) ECO-S
max length - 142,4 m;
max width - 29 m;
min draught - 8,5 m;
delivered power – 25 mW;
ice breaking capability (steady movement in continuous ice field) – 2 m ice thickness;
speed in ice-free water – 17 knots.
JSC Ob'edinyennaya Stroitel'naya Korporatsiya
December 2, 2011 No. 77-GK/11
December 2011 – advance payment made at the rate of 30% of the contract value.
January-September 2012 – vessel construction documentation elaborated, suppliers of equipment for the ice breaker agreed with FSUE “Rosmorport”.
October 2012 – keel laid down, two bottom sections No. 3001 and No. 3002 weighing 120 tons in total installed.
November-December 2012 - metal work cut, bottom sections formed and welded. Elaboration of vessel construction documentation continued, suppliers of equipment for the ice breaker agreed with FSUE “Rosmorport”.
January 2013:
- metal work cut, sections formed and welded;
- 2 sections of block 2 taken to the building berth and installed.
February 2013:
- 7 sections of block 3 and 4 sections of block 2 being manufactured. A section of block 2 being installed. Installation of 2 sections of block 2 completed;
- the vessel put onto the list of vessels under construction of the Russian Federation at number 49-0171;
- certificate on the registration of property right for the vessel received;
Vessel construction progress at the end of the month – 2,49%.
March 2013:
- 8 sections of block 2 and 8 sections of block 3 being manufactured. 3 sections of block 2 and a section of block 3 being installed.
Vessel construction progress at the end of the month – 3,11%.
April 2013:
- 4 sections of block 2 and 8 sections of block 3 being manufactured. 4 sections of block 2 and 3 sections of block 3 being installed.
Vessel construction progress at the end of the month - 3,71 %.
May 2013:
- 20 sections of block 2 and 8 sections of block 3 being manufactured. 4 sections of block 2 and 6 sections of block 3 being installed.
Installation of 3 sections of block 3 completed.
Vessel construction progress at the end of the month - 4,69%.
June 2013:
- 15 sections of block 2 and 10 sections of block 3 being manufactured;
- Installation of 5 sections of block 2 and 6 sections of block 3 completed.
Vessel construction progress at the end of the month - 5,8%.
October 2, 2015

General view

Right board view

Right board view

Back view

To perform dredging works to maintain established depth in the water area and on the approaches to the seaport of Sabetta for the purpose of ensuring navigation safety

Self-propelled self-discharging dredger with dredge drag head and hopper volume of 2000 m3

Vessel class: КМ 407-214e658e9e697fb1a413c9eeb941dd45.jpg Ice1 R1 AUT2 Dredger Hopper

Length: 86,5 м;

Width: 16,5 м;

Draft: 5,5 м;

Deadweight capacity: 3 057 t

Speed: 10 kt;

Minimal depth of soil excavation: 4 m;

Maximal depth of soil excavation: 22 m;

Hopper volume: 2,000 m3

Dredging pump capacity: 7,000 m3/hour

LLC “Onego Shipyard”
Contract No. 879/DO-16 of November 18, 2016
October 30, 2020

3-d model of the dredging vessel

3-d model of the dredging vessel

3-d model of the dredging vessel

3-d model of the dredging vessel

Plan of the vessel

Plan of the vessel

Self-propelled vessel is used for transportation of excavated soil during dredging to maintain predetermined depths in water areas and approaches to the seaport of Novorossiysk in order to ensure safety of navigation

Vessel Class:  КМ  Ice1 R3-RSN AUT3 Hopper*

Length: 53,8 meters

Width: 9,5 meters

Draft: 3,0 meters

Speed: 11 knots

Hopper capacity: 600 cubic meters

Speed: 6,5 knots

LLC “Onego Shipyard”

Contract No. 475/DO-15 dated August 20, 2015

October 5, 2018

3D model

Side view

Bow view

View from top

Self-propelled vessel is used for transportation of excavated soil

Vessel Class:  КМ  Ice1 R3-RSN AUT3 Hopper*

Length: 56.1 meters

Width: 11.2 meters

Draft: 2.92 meters

Speed: 11 knots

Hopper capacity: 600 cubic meters

Speed: 6.5 knots

Endurance by supplies of fuel, food and water: 5 days

Crew: 3 people

LLC “Onego Shipyard”

Contract No. 566/DO-18 dated October 15, 2018

September 30, 2018

3D model

Side view

Bow view

View from top

The vessel is designed to perform works on the installation and removal of floating facilities of the navigation equipment on the approaches to the Kaliningrad Seaport and in the water area of the seaport, as well as on the transportation of the two medium-size sea buoys of the C-3 type with anchor arrangements, their service in the water area

Vessel class: КМ  Ice3 R3-RSN AUT3

Length: 24 meter;

Width: 7,5 meter;

Draft: 1,7 meter;

Speed: 10 knots;

Total propulsive output: 560 kW
LLC “Onego Shipyard”
Contract No. 475/DO-15 dated August 20, 2015
Additional agrrement No. 1 of June 13, 2017
Additional agrrement No. 2 of December 12, 2017
Additional agrrement No. 3 of May 28, 2018
Additional agrrement No. 4 of September 6, 2018
October 5, 2018

Front view

Side view

View from top

The electric ship is intended to be used for delivering committees and crew members aboard vessels, as well as for performing functions of a pilot boat.

Vessel Class: КМ http://www.rosmorport.ru/uploadify/407-214e658e9e697fb1a413c9eeb941dd45.jpg Ice3 R2

Length: 21 meters

Width: 6 meters

Draft: 1.9 meters

Speed: 12 knots

Cruising endurance: 500 nautical miles

Endurance by supplies of fuel, food and water:5 days

Crew: 2 people

Special personnel: 10 people

LLC “Onego Shipyard”

Contract No. 345/DO-18 dated June 18, 2018

May 30, 2020

General view

Plan of the vessel

The electric ship is intended to be used for delivering committees and crew members aboard vessels, as well as for performing functions of a pilot boat.

Vessel Class: КМ http://www.rosmorport.ru/uploadify/407-214e658e9e697fb1a413c9eeb941dd45.jpg Ice3 R2

Length: 21 meters

Width: 6 meters

Draft: 1.9 meters

Speed: 12 knots

Cruising endurance: 500 nautical miles

Endurance by supplies of fuel, food and water:5 days

Crew: 2 people

Special personnel: 10 people

LLC “Onego Shipyard”

Contract No. 345/DO-18 dated June 18, 2018

May 30, 2020

General view

Plan of the vessel
